Key attributes
Industry-specific attributes
accuracy
±1%FS; ±0.5%FS; ±0.25%FS; ±0.15%FS; ±0.1%FS
Other attributes
customized support
OEM, ODM
model number
P100
material
304 Stainless steel
Measuring range
-0.1MPa … 0 … 0.1MPa … 100MPa
Overload pressure
Twice as rated pressure
Pressure type
Gauge pressure; absolute pressure
Measurement medium
Gas or liquid which is compatible with stainless steel
Measurement accuracy
±1%FS; ±0.5%FS; ±0.25%FS; ±0.15%FS; ±0.1%FS
Operating temperature
-20…+100℃
輸出信號
4~20mA/0-10V/0-5V/0.5~4.5V/RS485
Supply voltage
8-32VDC /12-32VDC /5VDC
Pressure connection
NPT1/4, NPT1/2, G1/4, G1/2, M20*1.5
Electrical connections
Large DIN, Cable outlet
Packaging and delivery
Selling Units:
Single item
Single package size:
20X20X15 cm
Single gross weight:
0.150 kg
